Super Yellow Color SMD Chip LED Diode 75mW AlGaInP Chip Material Indicator Applied

Product Categories
DOUBLE LIGHT ELECTRONICS TECHNOLOGY CO.,LTD
Contact Now

Super Yellow Color SMD Chip LED Diode 75mW AlGaInP Chip Material Indicator Applied

Brand Name : DOUBLE LIGHT

Model Number : DL-PCB1204UYC-3UY120

Certification : ISO9001:2008/ROHS

Place of Origin : China (mainland)

MOQ : 4000pcs

Price : US$ 0.03-0.033 per unit (Pieces)

Payment Terms : Telegraphic Transfer in Advance (Advance TT, T/T)

Supply Ability : 15,000,000pcs per Day

Delivery Time : 5-7 working days after received your payment

Packaging Details : Dimensions per Unit:0.28 × 0.2 × 0.13 Meters • Weight per Unit:3.5 Kilograms • Units per Export Carton:40000 • Export Carton Dimensions L/W/H: 0.45 × 0.28 × 0.27 Meters • Export Carton Weight:14.2 Kilograms

Product Name : 1204 SMD Chip Led

Package : 8mm tape on 7″ diameter reel

Peak Emission Wavelength : 592nm

Chip Material : AlGaInP

Lens Type : Water Clear

Forward Voltage @20ma : 2.0-2.8v

Luminous Intensity : 450-550mcd

Viewing Angle : 120 Deg

Dominant Wavelength : 589nm

Source Color : Super Yellow

Contact Now

592nm pcb led light super yellow color smd led diode 75mW pcb led light panel smd led chip light for Indicator

Know more details,please downlaod specifications:DL-PCB1204UYC-3UY120.pdf
Features:

  1. Package in 8mm tape on 7″ diameter reel.
  2. Compatible with automatic placement equipment.
  3. Compatible with infrared and vapor phase reflow solder process.
  4. 3.2mmX1.0mm SMT LED, 1.5mm .
  5. Low power consumption.
  6. Wide viewing angle.
  7. Ideal for backlight and indicator.
  8. AVAILABLE.Various colors and lens types available
  9. The product itself will remain within RoHS compliant Version.


Descriptions:

  1. The 1204 SMD LED is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained.
  2. Besides, lightweight makes them ideal for miniature applications, etc.


Applications:

  1. Automotive: Backlighting in dashboard and switch.
  2. Telecommunication: Indicator and backlighting in telephone and fax.
  3. Flat backlight for LCD, switch and symbol.
  4. General use.
Part No. Chip Material Lens Color Source Color
DL-PCB1204UYC-3UY120 AlGaInP Water Clear Super Yellow


Notes:

  1. All dimensions are in millimeters (inches).
  2. Tolerance is ± 0.10 mm (.004") unless otherwise specified.
  3. Specifications are subject to change without notice.

Absolute Maximum Ratings at Ta=25℃

Parameters Symbol Max. Unit
Power Dissipation PD 75 mW

Peak Forward Current

(1/10 Duty Cycle, 0.1ms Pulse Width)

 IFP 100 mA
Continuous Forward Current IF 25 mA
Reverse Voltage VR 5 V
Operating Temperature Range Topr -40℃ to +80℃
Storage Temperature Range Tstg -40℃ to +85℃
Soldering Temperature Tsld 260℃ for 5 Seconds


Electrical Optical Characteristics at Ta=25℃
Parameters Symbol Min. Typ. Max. Unit Test Condition
Luminous Intensity * IV 450 550 --- mcd IF=20mA (Note 1)
Viewing Angle * 2θ1/2 --- 120 --- Deg IF=20mA (Note 2)
Peak Emission Wavelength λp --- 592 --- nm IF=20mA
Dominant Wavelength λd --- 589 --- nm IF=20mA (Note 3)
Spectral Line Half-Width △λ --- 15 --- nm IF=20mA
Forward Voltage VF 2.00 2.20 2.80 V IF=20mA
Reverse Current IR --- --- 10 µA VR=5V

Notes:

  1. Luminous Intensity Measurement allowance is ± 10%.
  2. θ1/2 is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
  3. The dominant wavelength (λd) is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.

​Package Dimension:

Super Yellow Color SMD Chip LED Diode 75mW AlGaInP Chip Material Indicator Applied
Typical Electrical / Optical Characteristics Curves
(25℃ Ambient Temperature Unless Otherwise Noted)
Super Yellow Color SMD Chip LED Diode 75mW AlGaInP Chip Material Indicator Applied

HongKong Double Light Electronics was founded in 2005 as a professional LED manufacturer located in Shenzhen, China. We mainly produce a wide range of products with automatic production lines,which include THT LEDs, chip LEDs, LED displays, infrared LEDs, dot matrix, LCD backlights and LED lighting fixtures.
Super Yellow Color SMD Chip LED Diode 75mW AlGaInP Chip Material Indicator AppliedSuper Yellow Color SMD Chip LED Diode 75mW AlGaInP Chip Material Indicator Applied
Please contact with me to help you find your right product and get your best price .
Tel: 86-755-82853859
Fax: 86-755-83229774
Email:wendy@doublelight.com.cn
Wechat:ywj199111103964
Skype:wendy@doublelight.com.cn
