0.3 inch single digit display red color CA low power 7 segment display with wide viewing angle

Brand Name : DOUBLE LIGHT

Model Number : DL1-301ARB

Certification : ISO9001:2008/ROHS

Place of Origin : China (mainland)

MOQ : 1000pcs

Price : US$ 0.150-0.3per unit (Pieces) depends on the quantity

Payment Terms : Telegraphic Transfer in Advance (Advance TT, T/T)

Supply Ability : 5,000,000pcs per Day

Delivery Time : 15-20 working days after payment received

Packaging Details : Dimensions per Unit:0.28 × 0.2 × 0.13 Meters • Weight per Unit:3.5 Kilograms • Units per Export Carton:40000 • Export Carton Dimensions L/W/H: 0.45 × 0.28 × 0.27 Meters • Export Carton Weight:14.2 Kilograms

Product Name : 0.3 inch red Single digit 7 segment display

Emitted Color : Super Bright Red

Peak Emission Wavelength : 660nm

Face color : Black Surface

Forward Voltage @20ma : 1.8-2.4V per segment

Luminous Intensity : 5-10mcd

Led chip : GaAlAs

Display function : Audio/Instrument panels/read out display

Contact Now

Datasheet: DL1-301XRB.pdf


0.3 inch single digit display red color CA low power 7 segment display with wide viewing angle

outdoor 7 segment display features:

  1. 0.30″ (inch) digit height.
  2. Excellent segment uniformity.
  3. Sold state reliability.
  4. Industrial standard size.
  5. Low power consumption.
  6. The product itself will remain within RoHS compliant Version.

led numeric display descriptions:

  1. The DL1-301 series is a lager 7.8 mm (0.30″) high seven segments display designed for viewing distances
  2. up to 7 meters.
  3. These displays provide excellent reliability in bright ambient light.
  4. These devices are made with white segments and black surface.
  5. Emitted Color: Super Bright Red.


common anode 7 segment display applications:

  1. Audio equipment.
  2. Instrument panels.
  3. Digital read out display.


Package Dimension:

0.3 inch single digit display red color CA low power 7 segment display with wide viewing angle
0.3 inch single digit display red color CA low power 7 segment display with wide viewing angle

Notes:

  1. All dimensions are in millimeters (inches).
  2. Tolerance is ± 0.25 mm (.010″) unless otherwise noted.
  3. Specifications are subject to change without notice.


Device Selection Guide:

Model No.Chip MaterialSource ColorDescription
DL1-301ARBGaAlAsSuper Bright RedCommon Anode
DL1-301CRBSuper Bright RedCommon Cathode

Absolute Maximum Ratings at Ta=25℃

ParametersSymbolMax.Unit
Power Dissipation Per SegmentPD60mW

Peak Forward Current Per Segment

(1/10 Duty Cycle, 0.1ms Pulse Width)

IFP100mA
Forward Current Per SegmentIF25mA
Dating Linear From 50℃ 0.4mA/℃
Reverse VoltageVR5V
Operating Temperature RangeTopr-40℃ to +80℃
Storage Temperature RangeTstg-40℃ to +85℃
Soldering TemperatureTsld260℃ for 5 Seconds
Electrical Optical Characteristics at Ta=25℃
ParametersSymbolMin.Typ.Max.UnitTest Condition
Luminous IntensityIv5.010.0---mcdIF=20mA (Note 1)
Luminous Intensity Matching Ratio (Segment To Segment)Iv-m------2:1 IF=10mA
Peak Emission Wavelengthλp---660---nmIF=20mA
Dominant Wavelengthλd---640---nmIF=20mA (Note 2)
Spectral Line Half-Width△λ---20---nmIF=20mA
Forward VoltageVF---1.802.40VIF=20mA
Reverse CurrentIR------50µAVR=5V

Notes:

  • Luminous intensity is measured with a light sensor and filter combination that approximates the CIE eye-response curve.
  • The dominant wavelength (λd) is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.
