3535 Top View UV Power LED Diode 250mW Power Dissipation With Wide Viewing Angle

Brand Name : DOUBLE LIGHT

Model Number : DL-TOP3535UVC-310

Certification : ISO9001:2008/ROHS/REACH

Place of Origin : China (mainland)

MOQ : 10PCS

Payment Terms : Telegraphic Transfer in Advance (Advance TT, T/T)

Supply Ability : 15,000,000pcs per Day

Delivery Time : 5-7 working days after received your payment

Packaging Details : Dimensions per Unit:0.28 × 0.2 × 0.13 Meters • Weight per Unit:3.5 Kilograms • Units per Export Carton:40000 • Export Carton Dimensions L/W/H: 0.45 × 0.28 × 0.27 Meters • Export Carton Weight:14.2 Kilograms

Price : Negotiation

Emitted Color : UV Purple light

Power Dissipation : 250mW

Lens Color : Water Clear

Peak Wavelength : 305-315nm

Viewing Angle : 120 Deg

Continuous Forward Current : 40mA

Contact Now

3535 uv led chip purple SMD LED Diode Lights Top View UV LED Diode for light pipe application between 265nm 280nm 310nm

DL-TOP3535UVC-310.pdf

Features:

  1. White package.
  2. Optical indicator.
  3. Colorless clear window.
  4. Ideal for backlight and light pipe application.
  5. Inter reflector.
  6. View angle: 120°.
  7. Low current (2mA) operation.
  8. Wide viewing angle.
  9. Suitable for vapor-phase reflow, infrared reflow and wave solder processes.
  10. Computable with automatic placement equipment.

Descriptions:

The TOP3535 is available in soft red, orange, yellow, green, blue and white. Due to the Package design, the LED has wide viewing angle and optimized light coupling by inter reflector, this feature makes the SMT TOP LED ideal for light pipe Application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.

Applications:

  1. Automotive: Backlight in dashboards and switches.
  2. Telecommunication: Indicator and backlight in telephone and fax.
  3. Indicator and backlight for audio and video equipment.
  4. Indicator and backlight in office and family equipment.
  5. Flat backlight for LCD’s, switches and symbols.
  6. Light pipe application.
  7. General use.
  8. For disinfection


3535 Package Dimension:
3535 Top View UV Power LED Diode 250mW Power Dissipation With Wide Viewing Angle

Part No. Chip Material Lens Color Source Color
DL-TOP3535UVC-310 GaN Water Clear UV


Notes:

  1. All dimensions are in millimeters (inches).
  2. Tolerance is ± 0.25mm (.010”) unless otherwise specified.
  3. Specifications are subject to change without notice.

Absolute Maximum Ratings at Ta=25℃

Parameters Symbol Max. Unit
Power Dissipation PD 250 mW

Peak Forward Current

(1/10 Duty Cycle, 0.1ms Pulse Width)

 IFP 100 mA
Continuous Forward Current IF 40 mA
Reverse Voltage VR 5 V
Operating Temperature Range Topr -40℃ to +80℃
Storage Temperature Range Tstg -40℃ to +85℃
Soldering Temperature Tsld 260℃ for 5 Seconds
Electrical Optical Characteristics at Ta=25℃

Parameters Symbol Min. Typ. Max. Unit Test Condition
Radiant Power Ee 2.0 --- 3.5 Mw IF=40mA
Viewing Angle 2θ1/2 --- 120 --- Deg IF=40mA
Peak Wavelength wp 305 310 315 nm IF=40mA
Spectral Line Half-Width △λ --- 10 --- nm IF=40mA
Forward Voltage VF 5.2 6.0 6.8 V IF=40mA
Reverse Current IR --- --- 2 µA VR=5V
Company introduction:

HongKong Double Light Electronics was founded in 2005 as a professional LED manufacturer located in Shenzhen, China. We mainly produce a wide range of products with automatic production lines, which include THT LEDs, chip LEDs, LED displays, infrared LEDs, dot matrix, LCD backlights and LED lighting fixtures.

Why choose DOUBLE LIGHT?
1. Well-known chip material
2. 99.99% gold wire bonding
3. 3 years warranty
4. Over 10 years work experience technical service team
5. 24 hours service Professional sales team
6. Free Sample is available
7. Fast delivery
